V50S Dimension Weighing & Scanning System

Availability:

Available On Pre Order


The V50 DWS system is designed for accurate, reliable, and efficient capturing of shipment and production data (dimensions, weight, barcodes), with performance comparable to market leaders but at an affordable cost. Suitable for applications spanning from high-volume logistics and distribution companies to local shipping centers.

  • Increase Productivity: Eliminates errors through automated measuring process
  • Efficient: Scanning speed of 3,000 to 14,000 packages/hour
  • Reliable: Improve the processing efficiency of the next process with accurate and reliable capturing of shipment and production data.

The V50S helps to automate the following processes:
1) Dimensioning
2) Weighing
3) Barcode Scanning
4) Photo Taking Of Parcels
5) Data Transfer

Downloads

Product Brochure

Specifications

Camera Pixel: Barcode camera:12MP , dimension camera:1.3MP

Field of View: ≤400mmx600mm

Depth of View:≤500mm

Barcode Optical Resolution: 9.4mil

Barcode Type: EAN13/Code128/Code39/Code93 /interleaved2of 5/CodaBar/QR code/Data Matrix/EAN8/PDF 417/UPU,customized

Scanning Speed:2000+ Pcs/ H

Weighing Accuracy:±20g

Weighing Range:0.1-40kg

Weight: Single-sided printing: 11.3 lbs. (5.13 kg)s restrictions)*

Dimension Accuracy:±8mm

Dimension Measurement: 30*30*50mm-500*500*500mm

Camera: Processor:AIMB-B2281/I5-3450 Memory:4G/128G Hard Disk:1T SSD Windows10 64 PRO, Display: 21.5 Inch, Wireless Mouse: Included USB port, Audio: Included USB port

Camera: Industry Camera: 1.2 MP, Lens: 16mm distortionless high definition camera Switch: 12V,5A, LED: 6W

Scale: Platform Size: 60cm*45cm Scale Range: 40kg

Dimension Camera: Volumn Measuring: Dual-lens Camera

Convey Part: Conveyor Belt: Wear industrial grade belt, 5mm Electric Motor: Motorized roller, Driver: 48V, 485 Controller: USB switch to 485, Power Supply: 48V 10A

Stand: External Structure: L:W:H: 74*72*245cm, 205KG
